5-year guarantee EcoDesign 5 Class A+

Modern hybrid solution for wood and pellets Automatic fuel changeover - pellets or wood. SMARTFIRE COMBI 20/26

Efficiency:

93,54% / 93,90%

Output:

20kW / 26kW

How to buy?

Features

SMARTFIRE COMBI 20/26

5-year guarantee

5-year guarantee

High-quality materials and modern technologies used in production allow us to extend the warranty on the tightness of the boiler up to 5 years.

Show more Show less
EcoDesign

EcoDesign

EcoDesign 2020 Directive laid down restrictive requirements regarding emission and efficiency what is reflected in boiler actual use during the heating season.

Show more Show less
5 Class

5 Class

All boilers have been tested by an independent institute with EU notification to ensure reliable results that are recognized all over the world.

Show more Show less
A+

A+

Show more Show less
Cast iron safety airlock

Cast iron safety airlock

- reliability and protection in every situation.

Show more Show less
Stainless steel burner with automatic cleaning

Stainless steel burner with automatic cleaning

- high durability and ease of use.

Show more Show less
Colour touchscreen weather-compensated controller

Colour touchscreen weather-compensated controller

- energy savings and convenient control.

Show more Show less
Heat exchanger cleaning system

Heat exchanger cleaning system

- easy operation, consistently high efficiency.

Show more Show less
Automatic heat exchanger cleaning

Automatic heat exchanger cleaning

– consistently the highest possible efficiency.

Show more Show less
Induced draft fan

Induced draft fan

– reliable flue gas extraction and safe operation.

Show more Show less
Lambda sensor

Lambda sensor

– maximum combustion efficiency.

Show more Show less
Cooling coil

Cooling coil

– safety and easier installation.

Show more Show less
Automatic ash removal

Automatic ash removal

– complete user convenience.

Show more Show less
Ceramic nozzle

Ceramic nozzle

- stable wood combustion with lower emissions.

Show more Show less
Large loading door

Large loading door

– easy loading even of larger logs.

Show more Show less
Additional 480 L hopper

Additional 480 L hopper

(Optionally)
See the relevant data table

- installed on the right-hand side of the boiler to extend operating time between refills.

Show more Show less
Internet module

Internet module

(Optionally)
See the relevant data table

– remote control and service.

Show more Show less
VACUM system

VACUM system

(Optionally)
See the relevant data table

- automatic pellet transport from a large storage tank.

Show more Show less
Integrated hydraulic kit

Integrated hydraulic kit

(Optionally)
See the relevant data table

- thermostatic valve and energy-efficient pump.

Show more Show less

Description

SMARTFIRE COMBI 20/26

SmartFire Combi is a modern hybrid boiler for wood and pellets, combining comfort, flexibility and freedom in fuel selection. After loading the wood, the boiler automatically detects the fuel change, ignites the wood charge and, once it has burned out, automatically switches back to pellet operation.

As standard, the boiler is equipped with a cooling coil that increases safety and simplifies installation. Large doors and a spacious combustion chamber make it easier to load even larger logs. A cast-iron safety flap protects the pellet hopper against flame backburn.

Automatic heat exchanger cleaning helps maintain high efficiency over time. The automatic ash removal system with ash compression reduces the frequency of emptying the ash container to as little as 1-2 times per heating season. The pellet burner with a moving grate automatically removes ash and deposits, ensuring stable operation even when using lower-quality pellets.

Operation is managed by a weather-compensated controller for convenient adjustment of the heating system. SmartFire Combi meets the requirements of Class 5 and Ecodesign.

Show more Show less

Characteristics

SMARTFIRE COMBI 20/26

Model identifier SF COMBI 20/26
Energy efficiency class A+
Nominal heat output - wood 20 kW
Nominal heat output - pellet 26 kW
Energy efficiency index - wood 119,08
Energy efficiency index - pellet 120,11
Seasonal space heating energy efficiency - wood 81,02%
Seasonal space heating energy efficiency - pellet 81,53%

Technical Specification

SMARTFIRE COMBI 20/26

Parameters Unit SF COMBI 20/26
Boiler class - 5
Thermal efficiency - wood % 93,54
Thermal efficiency - pellets % 93,90
Rated output - wood kW 20
Rated output - pellets kW 26
Output range - pellets kW 6,08-26,29
Width mm 1105
Height mm 1490
Depth mm 1290
Boiler weight kg 600
Water capacity dm³ 100
Flue gas outlet diameter ext./int. mm 120/110
Recommended chimney diameter mm 120
Required chimney draught Pa/mbar 15/0,15
Flow/return connections inch 1
Maximum operating pressure bar 3
Average flue gas temperature at maximum output - wood °C 98
Average flue gas temperature at maximum output - pellets °C 88
Average flue gas temperature at minimum output - pellets °C 64
Maximum boiler temperature °C 85
Recommended boiler temperature °C 70÷80
Minimum return water temperature °C 65
Fuel hopper capacity dm³ 140
Show more Show less
